AOpen Digital Engine DE45 - Page 32

2-2 Install HDD on Supporter without ODD
2-2-1 Install Card Holder
Put the Card Holder on the supporter,
and screw it with 1pcs of M2 screw.
(Screwdriver torque : 0.7±0.1kgf.cm)
2-2-2.Insert the MPI-SATA card into HDD
Screw internal card to Card holder with 2pcs of
M2 screws.(Screwdriver torque:0.7±0.1kgf.cm)
22
