AOpen Digital Engine DE45 - Page 38

3-2. Install the supporter (Only HDD is on the supporter now)
3-2-1. Make sure the MPI-SATA card is correctly insert into the socket
3-2-2.Screw 4pcs of M3 screw at the
supporter.
(Screwdriver torque : 5.0 ± 0.2 kgf.cm)
28
