Motherboard Map
IrDA Connector
SYSFAN3 Connector
USB 2.0 Connector
4Mbit Flash ROM BIOS
ATA 66/100 IDE Connector x2
32-bit PCI Expansion Slot x3
JP14 CMOS Clear Jumper
Case Open Connector
Game Port Connector
Front Panel Connector
CD-IN Connector
PC99 Colored Back Panel
AUX-IN Connector
Onboard AC’97 CODEC
Front Audio Connector
Realtek RTL8101L LAN Chip
Resettable Fuse
JP28 Mouse/Keyboard Wakeup
2200μF Low ESR Capacitors
4-
p
in 12V. ATX Power Connector
COM2 Connector
SYSFAN2 Connector
FDD Connector
478-pin CPU socket with Voltage
and Frequency Auto-detection that
supports Intel
®
Pentium
®
4
1.4~2.4GHz+ CPU
Intel 845GL chipset
CPUFan1 Connector
184-pin DIMMx2
supports DDR266 (Max. to 2GB)
ATX Power Connector
PS. Here we use MX4LR-GN motherboard as illustration.
