Core Frequency = CPU FSB Clock * CPU Ratio
MX4LR-GN(100MHz x 4)
CPU
CPU Core
Frequency
FSB Clock
System
Bus
Ratio
Celeron 1.7G 1700MHz 100MHz 400MHz 17x
Celeron 1.8G 1800MHz 100MHz 400MHz 18x
Celeron 2.0G 2000MHz 100MHz 400MHz 20x
Pentium 4 1.6G 1600MHz 100MHz 400MHz 16x
Pentium 4 1.7G 1700MHz 100MHz 400MHz 17x
Pentium 4 1.8G 1800MHz 100MHz 400MHz 18x
Pentium 4 1.9G 1900MHz 100MHz 400MHz 19x
Pentium 4 2.0G 2000MHz 100MHz 400MHz 20x
Pentium 4 2.2G 2200MHz 100MHz 400MHz 22x
Pentium 4 2.4G 2400MHz 100MHz 400MHz 24x
MX4GVR-GN(133MHz x 4)
CPU
CPU Core
Fre
q
uenc
y
FSB Clock
System
Bus
Ratio
Pentium 4 2.4G 2400MHz 133MHz 533MHz 18x
Pentium 4 2.53G 2530MHz 133MHz 533MHz 19x
Pentium 4 2.66G 2660MHz 133MHz 533MHz 20x
Pentium 4 2.80G 2800MHz 133MHz 533MHz 21x
Pentium 4 3.06G 3060MHz 133MHz 533MHz 23x
PCI Clock = CPU FSB Clock / Clock Ratio
EV6 Bus Speed = CPU external bus clock x 2
Warning: To avoid possible CPU damage caused by
overheating, an automatic shutdown of system had been
especially designed on this motherboard. System would
be automatically power off when this motherboard with
implementation of THERMTRIP circuit detected a CPU
tem
p
erature above 135 de
g
ree.
Warning: Intel
®
845GL chipset supports maximum
400MHz (100MHz x 4) system bus and 66MHz AGP
clock; Intel
®
845GV chipset supports maximum 533Hz
(133MHz x 4) system bus and 66MHz AGP clock,
higher clock setting may cause serious system damage.
