1W x 2(Optional)
SPECIFICATION
LCD Panel
Driving system TFT Color LCD
Size 27"W(69cm)
Pixel pitch 0.311mm
Brightness
250nits
Contrast 100,000,000:1Max. (ACM)
Viewable angle 178° (H) 178° (V) (CR≥10) (Typical)
Response time 1ms( TVR)
Panel Type VA
H-Frequency
VGA: 31~67.5KHz,
HDMI(1.4): 31~84.5KHz
V-Frequency VGA: 60Hz ; HDMI(1.4): 48-75Hz，
Display Colors 16.7M
Dot Clock 180MHz
Max. Resolution 1920x1080 @75Hz
Plug & Play VESA DDCCI/DDC2B
Power consumption
ON Mode 24W
Standby mode 0.5W
0.3W
Input Connector
HDMI 1.4(Only HDMI Model)
VGA (Only VGA Model)
Input Video Signal
VGA signal (Only VGA-Input Model)
HDMI signal (Only HDMI-Input Model)
Speakers
Audio Audio-Output /Audio-Intput(Optional)
Maximum Screen Size
Horizontal:598mm
Vertical:336mm
Power Source 12V 3.0A---
Environmental
Considerations
Operating Temp: 0° to 40°C
Storage Temp: -20° to 60°C
Operating Humidity: 20% to 80%
Dimensions 614(W) x 452(H) x 224 (D) mm
Weight (N. W.) 3.92kg Unit (net)
Mechanism spec
Tilt: -5° to 15°
Detachable foot stand: Yes
External
Controls:
Functions
Brightness Refresh Rate Num
AMD FreeSync
TVR
Contrast
Black Boost
Low Blue Light
ACM
Super Sharpness
Auto Config
H.Postion
V.Position
Focus
Clock
Gamma
Color Temp.
Modes
sRGB Mode
Grayscale Mode
6-axis Hue
6-axis Saturate
Volume
Mute
Over Drive
Language
OSD Timeout
Transparency
OSD Lock
Input
Auto Source
Wide Mode
Hot Key Assignment
DDC/CI
HDMI Black Level
Quick Start Mode
Information
Save Setting to ...
Find manuals and other documents for your AOPEN product on the
AOPEN support website.
