4.ASSEMBLY AND SET UP
1. Assembly
1.Put down the scooter and make the
scooter stable
3.Loosen the 4 screws on the handlebar
steering valve. Put the handlebar on the
steering stem, pay attention to the correct
position, and tighten the screw with the tool
2.Install the kickstand, align them with the card holes
(below), and secure them using a 5MM hex wrench.
4.Install the headlight, align the screw position of
the seat fixing piece and lock the screw
5.To assemble the rear fender, install
the rear fork and the fixing holes on both
sides and tighten the screws
6.After assembly, turn on the battery switch
and power button below dashboard to check if
it’s working properly
