aoyue 2738 - ASSEMBLY AND PREPARATION

4
SPECIFICATIONS
ASSEMBLYANDPREPARATION
A.SolderingIron
1.Installsolderwiretothesolderironholder.
2.Attachthesolderingirontothe5pinoutputatthebottomrightareaofthemain
unit.
3.Placesolderingirontothesolderingironstandasshownabove.
B.SmokeAbsorber
Attachthesmokeabsorbingpentothesmokeabsorberoutput.Makesurethatthe
cordconnectionsarefreefromanytangles.
C.HotAirGun
Placethehotairguninthesensorcontrolledstandtoprepareforusage.
PowerInput: 220V
StationDimensions: 188(w)x126(h)x250(d)mm
W eight: 6Kg
SOLDERINGIRON
PowerConsumption: 70W
OutputVoltage: 24V
TemperatureRange: 200480
o
C
HeatingElementwithTip: CeramicHeater
TiptoGroundResistance: <2W
TiptoGroundPotential: <2mV
HOTAIR
PowerConsumption: 500W
TemperatureRange: 200480
o
C
HeatingElement: Metal HeatingCore
NozzletoGroundResistance: <2W
MotorType: DiaphragmPump
AirCapacity:
23 l /min(max)
SMOKEABSORBER
VacuumPressure: 600mmHg
