CONTROL PANEL GUIDE
LEGEND:
C — Main Power Swtitch
B1 — Soldering Iron Temperature Display.
B2 — Soldering Iron Temperature Adjustment Knob with Function On/Off
B3 — Soldering Iron 5-Pin Receptacle
A1 — Hot Air Gun Temperature Display
A2 — Hot Air Gun Airflow Adjustment Knob
A3 — Hot Air Gun Temperature Adjustment Knob with Function On/Off
A4 — Hot Air Gun Output Terminal
C
A1
A4
B3
B2
A3
A2
Back Panel
6
AC Power Plug
Fuse
B1
A
