A. Soldering Iron
1. Connect the soldering iron cord assembly to the soldering iron
output terminal .
2. Attach the sponge plate and solder spool holder(A) to the side
of the unit (B).
3. Place the soldering iron to the soldering iron stand.
4. Attach soldering iron spring holder as seen.
B. Hot Air Gun
The Hot Air Gun holder was
installed on the station
upside down for packaging
purpose. To set up the Hot
Air Gun holder:
1. Loosen the two screws
that secure the holder to
the station.
2. Turn the holder right
side up.
3. Re-fasten the two screws.
4. Place the hot air gun onto the
holder in preparation for usage.
7
ASSEMBLY and PREPARATIONS
A
