Connecting the speaker to a 100 volt speaker line
The speaker can be connected to 100 volt speaker lines and
has a power of 1.5, 3 or 6 watts. Select the wattage according
to the application. Never connect the 1.5, 3 or 6 watt wires
simultaneously!
Transformer output power taps are coded with a sticker on the 100
volt transformer.
In 100 volt systems, total system power is the sum of all speakers in
the system, e.g.
33 Watt
40 Watt Amplifier
The 100 volt amplifier output power must be equal or higher than the total speaker power!!!
