Technical specifications
Speaker type 6.5 inch coated dual paper cone
Rated power RMS 6W – 3W – 1.5W @ 100 volt
Nominal impedance 1666 ohms/6W/100V - 3333
ohms/3W/100V - 6666
ohms/1.5W/100V
Frequency range 90 – 19000 Hz
Sensitivity 94 dB spl 1W/1m
Max SPL 101 dB
Dispersion at 1 kHz 180°
Dispersion (-12 dB) at 4 kHz 150°
Chassis color white
Chassis type steel
Grille material steel
Removable grille yes
Fixing type metal dogears
IP classification 60
Dimensions outside Ø 205 mm
Dimensions cutout Ø 176-186 mm
Mounting depth 118 mm
Total depth including mounting
frame
120 mm
Speaker weight 1.5 kg
