7
Installation
Both 100 (70) volt and low
impedance (Lo-Z) connections
are provided for increased
installation flexibility. 100 (70)
V line with several transformer
power taps as well as low
impedance connectors are
hidden inside the cabinet. To
access the connector, open the
cabinet: remove the two philips
screws at the bottom of the
enclosure, see picture below.
In normal indoor situations you
can feed the cable(s) through
the rubber cable sleeves, for IP66
compatibility, use the supplied cable
entries and washers provided in the
accessory kit. A second cable entry
point is present for easily looping the
cable through.
