APART MA247 - Page 20

WWW.APART-AUDIO.COM

2XWSXWV
Zone 1 Line level output, balanced 0 dB on euroblock connector
Zone 2-6 100V outputs, zone 5 and 6 are limited to 70V compatible with
100V speakers. MAX 240 watt total power in 100V (180 watt
max in 1 zone).
Preselectable output levels: 5 steps + off + automatic bypass
(priority).
Minimum load impedance all zones summed: 41,66 ohms.
=RQHRXWSXWVRQHXUREORFNFRQQHFWRUDPSOL¿HUSRZHUFDQ
EHVXSSOLHGE\LQWHUQDORUH[WHUQDODPSOL¿HUVHOHFWDEOHZLWK
paging mode switch at the back panel)
Separate speaker out 50V/70V/100V and low impedance on euroblock.
Rec out 1V
Tuner out (MA247MR only) 300 mV
Pre amp out zone 2-6 1 V
Phantom power 18 VDC
Pre amp out zone1 1 V balanced on euroblock/100 ohm output impedance
Paging amp out 2 V balanced on euroblock/100 ohm output impedance
Priority out 24VDC, max 0,6A
Chime 2 tone chime activated by contact closure
,QSXWV
MIC/LINE 1 balanced input on euroblock
Sensitivity mic/line variable 3mV to 2V
Impedance ȍ
S/N mic/line !G%!G%
Phantom power NA
Frequency response 80Hz - 15kHz (+1/-3dB) speech eq
Muting activated by contact mutes inputs with lower priority by more than 40dB
Mic/line 2-4 balanced inputs on euroblock
Sensitivity mic/line variable 1,5mV to 200mV
Impedance ȍ
S/N mic/line !G%!G%
Phantom power 18 VDC
Frequency response 80Hz - 15kHz (+1/-3dB) speech eq
Muting activated by contact !G%
(PHUJHQF\LQSXWtransformer coupled balanced input on euroblock
Sensitivity 1V
