Muting circuit >40 dB
Operating temperature -10 to +45 °C
Relative humidity 10% - 90% non condensing
Dimensions H x W x D 88 (102 including feet) x 272
x 286 mm
Net weight 4.75 kg (5.9 kg)
Standard Accessories User manual, power cable
Optional accessories MA35/19 (19 inch mounting
brackets)
MICPAT-D, MICPACB-D (paging
microphone)
Inputs
MIC1 1 mV/600 ohms (balanced XLR,
TRS, DIN5), speech optimized filter
MIC2 1 mV/600 ohms (balanced XLR,
TRS), speech optimized filter
MIC3/LINE3 1 mV/600 ohms (balanced
XLR,TRS), 300 mV/47 kohm (RCA),
speech optimized filter
MIC 1-3 speech filter lo-cut @ 90 Hz
LINE4 300 mV / 15 kOhm
Amp in 1V (RCA)
S/N ratio mic >67 dB
S/N ratio line inputs >77 dB
Outputs
Pre Amp out 1V (RCA)
Record Out 350 mV (RCA)
Phantom power mic 1-2-3 approx 12-18 VDC
