Apator ELF User Manual

- 28 -
11. ANNEXES
Annex A. Display in the basic operating mode.
Heat consumption - permanent Legend
Other scenario examples
LCD test
Water volume
Supply temperature
Return temperature
Differential temperature
Instantaneous flow
Instantaneous power
Pulse Input 1
Pulse Input 2
Heat consumption at error
Depress and hold
Automatic
Short depress
Heat consumption in jumper ON time
Water volume w/o flow
Heat meter on return
Differential temperature on any sensor error
Error code - no sensors
Pulse input item not displayed
if the input is deactivated
Item not displayed if no error is present
Pulse Input 3
Pulse Input 4
Error codes
Group 01 - actual
Heat meter on supply
Calibration pulse constant
Pulse constant 1
Pulse constant 2
Pulse constant 3
LCD test
Current date
Current time
Operating time
Error operating time
Pulse constant 4
Firmware version
Firmware checksum
Serial number
User number
User number
Baud rate
Network number
Battery number
Cycle period 1 - average
Average power daily
Average flow daily
Average return temp. daily
Average supply temp. daily
Average power period
Average flow period
Average return temp. period
Average supply temp. period
Metrological test
Newer heat part
Newer volume part
Deactivated
Group 05 - testGroup 02 - monthlyGroup 03 - annualGroup 04 - service
