USER’S GUIDE network management card
3
Internal Management Features
Overview
The Management Card has two internal interfaces (control console and
Web interface) which provide menus with options that allow you to manage
the DC Power Plant and the Management Card. The Management Card’s
SNMP interface also allows you to use an SNMP browser with the
PowerNet
®
Management Information Base (MIB) to manage the DC Power
Plant.
Access priority for logging on
Only one user at a time can log onto the Management Card to use its
internal user interface features. The priority for access is as follows:
• Local access to the control console from a computer with a direct serial
connection to the Management Card always has the highest priority.
• Telnet access to the control console from a remote computer has
priority over Web access.
• Web access either directly or through the InfraStruXure Manager (for
InfraStruXure-compatible products), has the lowest priority.
f
For more information about the Management Card’s internal user
interfaces, see Control Console and Web Interface.
See also
To use the PowerNet MIB with an SNMP browser, see the
PowerNet
®
SNMP Management Information Base (MIB)
Reference Guide (\doc\en\Dcmibgde.pdf), which is provided on
the APC Network Management Card utility CD.
For information about how SNMP access to the Management
Card is controlled, see SNMP.

APC AP9617 Specifications

General

Type	Network Management Card
Model	AP9617
Data Link Protocol	Ethernet, Fast Ethernet
Network Ports Qty	1
Network Protocols	TCP/IP, HTTP, HTTPS, SNMP, Telnet, SSH
Management	SNMP
Compatibility	Smart-UPS
Remote Management Protocol	SNMP, HTTP, HTTPS, Telnet, SSH
Security	SSL, SSH
Operating Temperature	0 to 45 °C
Storage Temperature	-15 to 65 °C
Humidity	0 to 95% non-condensing
Ports	RJ-45 Ethernet
