APC Symmetra LX Startup Guide

6Symmetra LX Start Up Guide
3 . If the output voltage is not correct for your application use the arrow keys and ENTER to select
‘Output’. The cursor will move to the voltage field, as the up and down arrows scroll through
available choices. Select the desired voltage setting and press ENTER.
Turn On the Load Equipment
The Symmetra LX must be turned on before executing this procedure.
1 . Press ‘Esc’ until the Main Menu appears. Use the up and down arrow keys to choose ‘Control’ and
ENTER to select it.
2 . Use the arrow keys and ENTER to select ‘Turn UPS Output On’. NOTE: You must scroll down to a
second page of choices.
3 . Confirm choice by selecting ‘YES’.
4 . There will be clicking sounds and this message will appear. NOTE: You may be given one or more
override warnings. Answer these by selecting ‘Start Now’.
5 . In approximately 90 seconds, the green Load On indicator will illuminate and this message will
appear.
Self Test: Enabled
UPS ID: UPS_IDEN
Vout Reporting: AUTO
>Output: 208V
>Control
Status
Setup
Accessories
Logging
Display
Diags
Help
Graceful Turn Off
Start Runtime Cal
>Turn UPS Output On
Confirm:
Turn UPS On
CANCEL
>YES, Turn UPS On
UPS HAS BEEN COMMANDED TO
TURN LOAD POWER ON
UPS LOAD IS ON
Press any key...

APC Symmetra LX Specifications

General

Form factor	1U
Certification	CSA, UL 1778
Product color	Silver
Battery voltage	120 V
Battery capacity	864000 mAh
Battery technology	Sealed Lead Acid (VRLA)
Dimensions (WxDxH)	210 x 546 x 140 mm
Battery life	3 year(s)
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-15 - 45 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	85079080

Weight and Dimensions

Weight	29100 g
Package weight	32280 g
