Apel BR–5000N - Control Panel Keys, Display and Indicator

BR5N-1-OMA-103a 7
2.2 Control panel Keys, Display and Indicator
Fig.１
１１
１
1. LCD Display 7. Power switch
2. Pilot lamp 8. Fuse holder
3. Control panel 9. AC Power socket
4. Serum gauge 10. Printer Interface Connector(D-sub25p,female)
5. Capillary tube holder 11. RS-232C Interface Connector(D-sub9p,male)
6. Serial number label
1
2
3
4
56
7
8
9 10 11
FUSE FUSE
1
４ ５ ６
７
８
9
DEL
START
SET
CAL
PRINT
No
A～Ｚ
２
３ ０
ZERO
μmol/dl
mg/dl
EXIT
( ) ( )
Control Panel
