Technical Specification
Cooking Hob
UBIND60FLC
Cooking Zones
4 Zones
Supply Voltage
220-240V~
Installed Electric Power
6400W
Product Size L×W×H(mm)
590X520X58
Building-in Dimensions A×B (mm)
565X495
Weight and Dimensions are approximate. Because we continually strive to
improve our products we may change specifications and designs without prior
notice.
Installation
Selection of installation equipment
Cut out the work surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 5 cm space shall be
preserved around the hole.
Be sure the thickness of the work surface is at least 30 mm. Please select
heat-resistant work surface material to avoid larger deformation caused by the
heat radiation from the hotplate. As shown below:
L(mm)
W(mm)
H(mm)
D(mm)
A(mm)
B(mm)
X(mm)
590
520
58
54
565
495
50 mini
Make sure the Induction cooker hob is well ventilated
