YOUR OVEN
UBMFTC90SS
A. Cooking mode selection dial - Top and bottom ovens
B. Cooking temperature selection dial
C. Electronic programmer - allows you to programme the
desired cooking by selecting the cooking time and the
end cooking time. It can also be used as a timer (only
available on certain models)
D.
Oven indication light. When lit, it indicates the ovens is
heating up to the temperature set
YOUR CONTROL PANEL
AB B
C
D
D
YOUR ELECTRONIC PROGRAMMER
1. Timer
2. Cooking time
3. End cooking time
4. Clock
5. Display
6. – button
7. Mode change
8. + button
1
2 3
4
5
6
8
7
a. Control panel
b. Shelf guides
c. Oven shelf
d. Grill pan set
YOUR OVEN
a
b
b
d
A
c
