Use the crowbar in the package to tuck the cable neatly across the top of
the windscreen and down the side to keep the cable out of eyesight and
tidier (the wires can be hidden neatly into the small gap between the roof
lining and the windscreen).
Connect the other end of the car charger cable to the cigarette lighter;
connect the other end of the rear camera cable to the rear camera. Attach
the rear view camera on the rear windshield. As shown below.
4. Other installation steps to complete
Connect the car charger cable with the front camera; connect the rear
camera cable with the rear camera interface on the front camera. As
shown below.
Rear Camera Connection Port
Car Chager Interface
