ARCHMI-8XX Series User Manual
8
Chapter 1 Getting Started
1.1 Features
 7”/8”/10.1”/12.1”/15”/15.6”/17”/18.5”/19”/21.5” Industrial Compact Size
Panel PC
 Flat front panel touch screen and fanless design
 Aluminum die-casting chassis for ARCHMI-816(P)
 Intel Celeron N2930(1.83GHz) CPU built-in/Atom E3845(1.91GHz) for option
 Onboard 4GB DDR 3L 1600 MHz/8GB(option)
 9~36VDC wide-ranging power input
 IP65 compliant front panel
 Optional projected capacitive touchscreen support 7H anti-scratch surface
1.2 Specifications
ARCHMI-8XX Series
System
CPU
Onboard Intel Celeron N2930(1.83GHz )/Atom E3845(1.91GHz) for option
Chipset
SoC
Memory
Onboard 4GB DDR 3L 1600 MHz/8GB(option)
IO Port
USB
2 x USB 3.0 type A
Serial/Parallel
1 x RS-232 DB-9(COM2)
1 x DB-9 RS-232/422/485 (Default RS-232)(COM1)
Audio
1 x Audio Line Out
LAN
2 x GbE LAN RJ-45
Power
1 x 3-pin DC Power input terminal
1 x 2-pin connector for power on/off button
Option
(Not available for
ARCHMI-807 and
ARCHMI-808)
2 x RS-232 DB-9 + 1 x Mini-PCIe slot via TB-528C2ME1
2 x CAN bus via TB-528CAN2
2 x USB 2.0 type A Via TB-528U2
2 x USB 2.0 type A + 1 x Mini-PCIe slot + 1xRS-232 DB-9 + 1 x Power button
via TB-528C1U2P1 (TB-528C1U2 for ARCHMI-810)
