Diagram # Part # Description Quantity
1 A4501 Compressor Deck 1
2 A4198 110v Mini Compressor Unit 1
3 A4320 1/4" X 20 X 1/2" Hex Bolt Plated .5. 12
4 A4300 1/4" SAE F/W Plated Washer 16
5 A4308 1/4" X 20 Hex Nuts Plated 4
6 A9016 Rubber Foot 4
7 A4998 Pressure Regulator 1
8 A4503 1/8" Male NPT X 1/4" Male Hose Barb 90° 1
9 A4033 Air Line Hose Clip S.S. 2
10 A2116 1/4" Air Hose, Per Foot 3
11 A2119 1/4" X 1/4" Female Swivel Barb 1
12 A4026 Quick Connect Female With 1/4" Male Thread 1
13 A4310 1/4" X 20 Cap Nut Plated 8
14 A4502 Pressure Pot Support Bracket 1
15 A4613 Rubber Edge Trim 2
16 A4200 2 Quart Pressure Pot W/Single Regulator 1
