CAUTION
● The grease used for lubrication of the O-rings must be the silicone grease
specified by Nippon Sensuiki.
Other types of grease can cause the plastic in the housing to split and for O-rings
to expand which may cause serious leakage to occur.
Please note that the damage caused by the use of grease other than that specified
by Nippon Sensuiki will avoid any warranty.
CAUTION
● Please never use organic solvents such as gasoline, oil, petroleum,
grease (Vaseline included), alcohol, the toluene, methyl, ethyl, ketones,
and acetones nor strong detergents, etc.
● Please disconnect the plug from the battery during storage.
● Please keep the box the scooter is delivered in.
This box will help prevent damage during transport.
There are four main sealing O-rings. Two large
O-rings between the top cover (head Assy) and
body Assy, and two smaller ones between the
body Assy and propeller Assy.
You must replace these O-rings if they are in any
way damaged, deformed, or creased.
We highly recommend that these O-rings be
changed annually.
Please use an O-ring pick made of soft plastic
when removing the O-ring from the groove.
Please never use a screwdriver or a sharp tool.
Impact absorbent acrylonitrile-butadiene-styrene resin is used for the body of the av-2 series, AVX and scooter
saddle.
This material excels in strength and durability, and looks great after years of service.
However, the material may be seriously compromised and damaged if you use the wrong lubricants
and or cleaners. Please note the following.
Please execute "Desalt" process on all moving parts.
Especially the accelerator lever.
■STEP1 The main sealing O-rings.
■STEP2 Body
■STEP3 Accelerator unit
■STEP4 Storage notice
Note on Maintenance and storage.
Remove the battery socket
Please keep the package
●O-rings for body
●O-rings for propeller Assy
(All apollo DPV)
21
To Next Page
