Apollo RP4A User Manual

21
Customer Service (704) 841-6000
backflow.apollovalves.com
ES1600 REV A.
BFMMRP4ALBF
REPAIR KITS (MAINLINE) 8” - 12”
CHECK RUBBER ONLY KIT
(ONE KIT REPAIRS ONE CHECK)
SIZE
8” 10” & 12”
REPAIR KIT MODEL NUMBER RK4A8CMR RK4A12INCMR
Item # Ordering Number 4A-00E-01 4A-00H-01
not shown Lubricant I-9016-00
19 Disc D-4934-00 D-4960-00
17 Check O-ring D-4935-00 D-4997-00
7 Relief Valve Port O-ring D-4963-00 D-2304-00
RP FIRST CHECK COMPLETE KIT
(ONE KIT REPAIRS ONE CHECK)
SIZE
8” 10” & 12”
REPAIR KIT MODEL NUMBER RK4A8PCM RK4A12INPCM
ITEM # ORDERING NUMBER 4A-00E-03 4A-00H-03
not Shown Lubricant I-9016-00
16 1st Check Module S-Assy W-9674-05 W-9863-05
17 Check O-ring D-4935-00 D-4997-00
RP SECOND CHECK COMPLETE KIT
(ONE KIT REPAIRS ONE CHECK)
SIZE
8” 10” & 12”
REPAIR KIT MODEL NUMBER RK4A8DCRP2CMC RK4A12INDCRP2CMC
ITEM # ORDERING NUMBER 4A-00E-14 4A-00H-14
not shown Lubricant I-9016-00
11 2nd Check Module S-Assy W-9673-05 W-9862-05
17 Check O-ring D-4935-00 D-4997-00
RP RELIEF VALVE RUBBER KIT
SIZE
8” 10” & 12”
REPAIR KIT MODEL NUMBER RK4A8RVR RK4A12INRVR
ITEM # ORDERING NUMBER 4A-00E-04 4A-00H-04
not shown Lubricant I-9016-00
29 RV Seat O-ring D-4883-00 D-3506-00
31 Bushing O-ring D-2565-00 D-4858-00
33 Diaphragm D-2564-00 D-2591-00
39 RV Seat Disc D-2563-00 D-2595-00
41 Stem O-ring D-2562-00 D-2594-00
not shown Dia. Plate O-ring N/A D-2512-00
7 Relief Valve Port O-ring D-4963-00 D-2304-00
RP RELIEF VALVE COMPLETE KIT
SIZE
8” 10” & 12”
REPAIR KIT MODEL NUMBER RK4A8RVC RK4A12INRVC
ITEM # ORDERING NUMBER 4A-00E-05 4A-00H-05
not shown Lubricant I-9016-00
33 Diaphragm D-2564-00 D-2591-00
29 RV Seat O-ring D-4883-00 D-3506-00
30 RV Seat Cage L- 8 0 47- 0 0 L- 8 1 69 - 0 0
31 Bushing O-ring D-2565-00 D-4858-00
32 RV Module W-9675-00 W-2330-05
7 Relief Valve Port O-ring D-4963-00 D-2304-00
Note: All bronze components listed are lead-free*
*LEAD FREE: The wetted surfaces of this product shall contain no more than 0.25% lead by weighted average. Complies with CA
AB1953, VT Act 193, MD HB372, LA HB471, and Federal Public Law 111-380.
REPAIR KITS - 8” - 12”
