Apollo RPLF4A User Manual

18
Customer Service (704) 841-6000
www.apolloflowcontrols.com
“Apl”
Flow Controls
INSTALLATION, OPERATION & MAINTENANCE
MANUAL
REPAIR KITS (MAINLINE) 2-1/2” - 6”
CHECK RUBBER ONLY KIT
(ONE KIT REPAIRS ONE CHECK)
SIZE
2-1/2” & 3” 4” 6”
REPAIR KIT MODEL NUMBER RK4A3CMR RK4A4CMR RK4A6CMR
ITEM # ORDERING NUMBER 4A-000-01 4A-00A-01 4A-00C-01
not shown Lubricant I-9016-00
25 Disc D-4958-00 D-4862-00 D-4890-00
24 Check Seat O-ring D-5171-00 D-4869-00 D-5000-00
8 Relief Valve Port O-ring D-4866-00
16 Cover O-ring D-4976-00 D-4870-00 D-5001-00
15 Test Cock O-ring D-4892-00 D-3904-00
RP FIRST CHECK COMPLETE KIT
(ONE KIT REPAIRS ONE CHECK)
SIZE
2-1/2” & 3” 4” 6”
REPAIR KIT MODEL NUMBER RK4A3RPCMC RK4A4RPCMC RK4A6RPCMC
ITEM # ORDERING NUMBER 4A-000-03 4A-00A-03 4A-00C-03
not shown Lubricant I-9016-00
20 1st Check Module S-Assy W-9855-05 W-9666-05 W-9670-05
24 Check O-ring D-5171-00 D-4869-00 D-5000-00
16 Cover O-ring D-4976-00 D-4870-00 D-5001-00
RP SECOND CHECK COMPLETE KIT
(ONE KIT REPAIRS ONE CHECK)
SIZE
2-1/2” & 3” 4” 6”
REPAIR KIT MODEL NUMBER RK4A3DCRP2CMC RK4A4DCRP2CMC RK4A6DCRP2CMC
ITEM # ORDERING NUMBER 4A-000-14 4A-00A-14 4A-00C-14
not shown Lubricant I-9016-00
12 2nd Check Module S-Assy W-9857-05 W-9667-05 W-9671-05
24 Check O-ring D-5171-00 D-4869-00 D-5000-00
16 Cover O-ring D-4976-00 D-4870-00 D-5001-00
RP RELIEF VALVE RUBBER KIT
REPAIR KIT MODEL NUMBER RK4A6RVR
ITEM # ORDERING NUMBER 4A-00C-04
not shown Lubricant I-9016-00
34 RV Seat O-ring D-4867-00
36 Bushing O-ring D-4883-00
42 RV Seat Disc D-4863-00
44 Stem O-ring D-4744-00
48 Diaphragm D-4861-00
50 Diaphragm Plate O-ring D-4865-00
8 Relief Valve Port O-ring D-4866-00
RP RELIEF VALVE COMPLETE KIT
REPAIR KIT MODEL NUMBER RK4A6RVC
ITEM # ORDERING NUMBER 4A-00C-05
not shown Lubricant I-9016-00
34 RV Seat O-ring D-4867-00
35 Seat Cage L-7 9 9 5 - 0 0
36 Bushing O-ring D-4883-00
37 RV Module W-9677-05
8 Relief Valve Port O-ring D-4866-00
Note: All bronze components listed are lead-free*
*LEAD FREE: The wetted surfaces of this product shall contain no more than 0.25% lead by weighted average. Complies with CA
AB1953, VT Act 193, MD HB372, LA HB471, and Federal Public Law 111-380.
REPAIR KITS - 2-1/2” - 6”
