Apollo RPLF4A User Manual

37
Customer Service (704) 841-6000
backflow.apollovalves.com
ES1600 REV A.
BFMMRP4ALBF
SHUT-OFF VALVE PART NUMBERS
(UL LISTED ASSEMBLIES MUST HAVE INDICATING TYPE SHUT-OFF VALVES ON INLET AND OUTLET.)
SHUT-OFF VALVE OPTIONS -- 2-1/2”
ASSEMBLY DESCRIPTION (INLET X OUTLET) INLET OUTLET SUFFIX
FLANGE NRS X FLANGE NRS W-5310-00 W-5310-00 -02
FLANGE OS&Y X FLANGE OS&Y W-4733-00 W-4733-00 -03
FLANGE OS&Y X MONITORED BFV W-4733-00 W-5244-00 -04
FLANGE OS&Y X GROOVED OS&Y W-4733-00 W-5282-00 -07
GROOVED OS&Y X GROOVED OS&Y W-5282-00 W-5282-00 -08
MONITORED BFV X MONITORED BFV W-5244-00 W-5244-00 -09
GROOVE NRS X GROOVE NRS W-9369-00 W-9369-00 -011
FLANGE NRS X GROOVE NRS W-5310-00 W-9369-00 -012
SHUT-OFF VALVE OPTIONS -- 3”
ASSEMBLY DESCRIPTION (INLET X OUTLET) INLET OUTLET POST PLATE OPERATING NUT SUFFIX
FLANGE NRS X FLANGE NRS W-5311-00 W-5311-00 N/A N/A -02
FLANGE OS&Y X FLANGE OS&Y W-4734-00 W-4734-00 N/A N/A -03
FLANGE OS&Y X MONITORED BFV W-4734-00 W-5245-00 N/A N/A -04
FLANGE OS&Y X FLANGE POST INDICATOR W-4734-00 W-5311-00 E-2922-00 C-2640-00 -06
FLANGE OS&Y X GROOVE OS&Y W-4734-00 W-5283-00 N/A N/A -07
GROOVE OS&Y X GROOVE OS&Y W-5283-00 W-5283-00 N/A N/A -08
MONITORED BFV X MONITORED BFV W-5245-00 W-5245-00 N/A N/A -09
FLANGE OS&Y X GROOVE POST INDICATOR W-4734-00 W-9370-00 E-2922-00 C-2640-00 -010
GROOVE NRS X GROOVE NRS W-9370-00 W-9370-00 N/A N/A -011
FLANGE NRS X GROOVE NRS W-5311-00 W-9370-00 N/A N/A -012
FLANGE POST INDICATOR X MONITORED BFV W-5311-00 W-5245-00 E-2922-00 C-2640-00 -013
FLANGE POST INDICATOR X FLANGE POST INDICATOR W-5311-00 W-5311-00 E-2922-00 C-2640-00 -014
MONITORED BFV X FLANGE POST INDICATOR W-5245-00 W-5311-00 E-2922-00 C-2640-00 -016
FLANGE POST INDICATOR X GROOVE OS&Y W-5311-00 W-5283-00 E-2922-00 C-2640-00 -017
GROOVE OS&Y X GROOVE POST INDICATOR W-5283-00 W-9370-00 E-2922-00 C-2640-00 -018
MONITORED BFV X GROOVE POST INDICATOR W-5245-00 W-9370-00 E-2922-00 C-2640-00 -019
FLANGE POST INDICATOR X FLANGE OS&Y W-5311-00 W-4734-00 E-2922-00 C-2640-00 -020
SHUT-OFF VALVES

Apollo RPLF4A Specifications

General

Brand	Apollo
Model	RPLF4A
Category	Control Unit
Language	English
