INSTALLATION, OPERATION & MAINTENANCE
MANUAL
SHUT-OFF VALVE PART NUMBERS
(UL LISTED ASSEMBLIES MUST HAVE INDICATING TYPE SHUT-OFF VALVES ON INLET AND OUTLET.)
SHUT-OFF VALVE OPTIONS -- 4”
ASSEMBLY DESCRIPTION (INLET X OUTLET) INLET OUTLET POST PLATE OPERATING NUT SUFFIX
FLANGE NRS X FLANGE NRS W-2870-00 W-2870-00 N/A N/A -02
FLANGE OS&Y X FLANGE OS&Y W-2889-00 W-2889-00 N/A N/A -03
FLANGE OS&Y X MONITORED BFV W-2889-00 W-5246-00 N/A N/A -04
FLANGE OS&Y X FLANGE POST INDICATOR W-2889-00 W-2870-00 E-3025-00 C-2776-00 -06
FLANGE OS&Y X GROOVE OS&Y W-2889-00 W-2895-00 N/A N/A -07
GROOVE OS&Y X GROOVE OS&Y W-2895-00 W-2895-00 N/A N/A -08
MONITORED BFV X MONITORED BFV W-5246-00 W-5246-00 N/A N/A -09
FLANGE OS&Y X GROOVE POST INDICATOR W-9126-00 W-2876-00 E-3025-00 C-2776-00 -010
GROOVE NRS X GROOVE NRS W-2876-00 W-2876-00 N/A N/A -011
FLANGE NRS X GROOVE NRS W-2870-00 W-2876-00 N/A N/A -012
FLANGE POST INDICATOR X MONITORED BFV W-2870-00 W-5246-00 E-3025-00 C-2776-00 -013
FLANGE POST INDICATOR X FLANGE POST INDICATOR W-2870-00 W-2870-00 E-3025-00 C-2776-00 -014
MONITORED BFV X FLANGE POST INDICATOR W-5246-00 W-2870-00 E-3025-00 C-2776-00 -016
FLANGE POST INDICATOR X GROOVE OS&Y W-2870-00 W-2895-00 E-3025-00 C-2776-00 -017
GROOVE OS&Y X GROOVE POST INDICATOR W-2895-00 W-2876-00 E-3025-00 C-2776-00 -018
MONITORED BFV X GROOVE POST INDICATOR W-5246-00 W-2876-00 E-3025-00 C-2776-00 -019
FLANGE POST INDICATOR X FLANGE OS&Y W-2870-00 W-2889-00 E-3025-00 C-2776-00 -020
GROOVE POST INDICATOR X GROOVE OS&Y W-2876-00 W-2895-00 E-3025-00 C-2776-00 -021
GROOVE POST INDICATOR X MONITORED BFV W-2876-00 W-5246-00 E-3025-00 C-2776-00 -022
MONITORED BFV X FLANGE OS&Y W-5246-00 W-2889-00 E-3025-00 C-2776-00 -023
SHUT-OFF VALVE OPTIONS -- 6”
ASSEMBLY DESCRIPTION (INLET X OUTLET) INLET OUTLET POST PLATE OPERATING NUT SUFFIX
FLANGE NRS X FLANGE NRS W-2871-00 W-2871-00 N/A N/A -02
FLANGE OS&Y X FLANGE OS&Y W-2890-00 W-2890-00 N/A N/A -03
FLANGE OS&Y X MONITORED BFV W-2890-00 W-5247-00 N/A N/A -04
FLANGE OS&Y X FLANGE POST INDICATOR W-2890-00 W-2871-00 E-2036-00 C-2777-00 -06
FLANGE OS&Y X GROOVE OS&Y W-2890-00 W-2896-00 N/A N/A -07
GROOVE OS&Y X GROOVE OS&Y W-2896-00 W-2896-00 N/A N/A -08
MONITORED BFV X MONITORED BFV W-5247-00 W-5247-00 N/A N/A -09
FLANGE OS&Y X GROOVE POST INDICATOR W-2890-00 W-2877-00 E-2036-00 C-2777-00 -010
GROOVE NRS X GROOVE NRS W-2877-00 W-2877-00 N/A N/A -011
FLANGE NRS X GROOVE NRS W-2871-00 W-2877-00 N/A N/A -012
FLANGE POST INDICATOR X MONITORED BFV W-2871-00 W-5247-00 E-2036-00 C-2777-00 -013
FLANGE POST INDICATOR X FLANGE POST INDICATOR W-2871-00 W-2871-00 E-2036-00 C-2777-00 -014
MONITORED BFV X FLANGE POST INDICATOR W-5247-00 W-2871-00 E-2036-00 C-2777-00 -016
FLANGE POST INDICATOR X GROOVE OS&Y W-2871-00 W-2896-00 E-2036-00 C-2777-00 -017
GROOVE OS&Y X GROOVE POST INDICATOR W-2896-00 W-2877-00 E-2036-00 C-2777-00 -018
MONITORED BFVY X GROOVE POST INDICATOR W-5247-00 W-2877-00 E-2036-00 C-2777-00 -019
FLANGE POST INDICATOR X FLANGE OS&Y W-2871-00 W-2890-00 E-2036-00 C-2777-00 -020
GROOVE POST INDICATOR X GROOVE OS&Y W-2877-00 W-2896-00 E-2036-00 C-2777-00 -021
GROOVE POST INDICATOR X MONITORED BFV W-2877-00 W-5247-00 E-2036-00 C-2777-00 -022
MONITORED BFV X FLANGE OS&Y W-5247-00 W-2890-00 E-2036-00 C-2777-00 -023
SHUT-OFF VALVES
