SHUT-OFF VALVE OPTIONS -- 12”
ASSEMBLY DESCRIPTION (INLET X OUTLET) INLET OUTLET POST PLATE OPERATING NUT SUFFIX
FLANGE NRS X FLANGE NRS W-2867-00 W-2867-00 N/A N/A -02
FLANGE OS&Y X FLANGE OS&Y W-2886-00 W-2886-00 N/A N/A -03
FLANGE OS&Y X FLANGE POST INDICATOR W-2886-00 W-2867-00 E-3027-00 C-2778-00 -06
SHUT-OFF VALVE PART NUMBERS
(UL LISTED ASSEMBLIES MUST HAVE INDICATING TYPE SHUT-OFF VALVES ON INLET AND OUTLET.)
SHUT-OFF VALVE OPTIONS -- 8”
ASSEMBLY DESCRIPTION (INLET X OUTLET) INLET OUTLET POST PLATE OPERATING NUT SUFFIX
FLANGE NRS X FLANGE NRS W-2872-00 W-2872-00 N/A N/A -02
FLANGE OS&Y X FLANGE OS&Y W-2890-00 W-2890-00 N/A N/A -03
FLANGE OS&Y X MONITORED BFV W-2890-00 W-5248-00 N/A N/A -04
FLANGE OS&Y X FLANGE POST INDICATOR W-2890-00 W-2872-00 E-3026-00 C-2777-00 -06
FLANGE OS&Y X GROOVE OS&Y W-2890-00 W-2897-00 N/A N/A -07
GROOVE OS&Y X GROOVE OS&Y W-2897-00 W-2897-00 N/A N/A -08
MONITORED BFV X MONITORED BFV W-5248-00 W-5248-00 N/A N/A -09
FLANGE OS&Y X GROOVE POST INDICATOR W-2890-00 W-2878-00 E-3026-00 C-2777-00 -010
GROOVE NRS X GROOVE NRS W-2878-00 W-2878-00 N/A N/A -011
FLANGE NRS X GROOVE NRS W-2872-00 W-2878-00 N/A N/A -012
FLANGE POST INDICATOR X MONITORED BFV W-2872-00 W-5248-00 E-3026-00 C-2777-00 -013
FLANGE POST INDICATOR X FLANGE POST INDICATOR W-2872-00 W-2872-00 E-3026-00 C-2777-00 -014
MONITORED BFV X FLANGE POST INDICATOR W-5248-00 W-2872-00 E-3026-00 C-2777-00 -016
FLANGE POST INDICATOR X GROOVE OS&Y W-2872-00 W-2897-00 E-3026-00 C-2777-00 -017
GROOVE OS&Y X GROOVE POST INDICATOR W-2897-00 W-2878-00 E-3026-00 C-2777-00 -018
MONITORED BFV X GROOVE POST INDICATOR W-5248-00 W-2878-00 E-3026-00 C-2777-00 -019
FLANGE POST INDICATOR X FLANGE OS&Y W-2872-00 W-2890-00 E-3026-00 C-2777-00 -020
GROOVE POST INDICATOR X GROOVE OS&Y W-2878-00 W-2897-00 E-2036-00 C-2777-00 -021
GROOVE POST INDICATOR X MONITORED BFV W-2878-00 W-5248-00 E-2036-00 C-2777-00 -022
MONITORED BFV X FLANGE OS&Y W-5248-00 W-2890-00 E-2036-00 C-2777-00 -023
SHUT-OFF VALVE OPTIONS -- 10”
ASSEMBLY DESCRIPTION (INLET X OUTLET) INLET OUTLET POST PLATE OPERATING NUT SUFFIX
FLANGE NRS X FLANGE NRS W-2873-00 W-2873-00 N/A N/A -02
FLANGE OS&Y X FLANGE OS&Y W-2892-00 W-2892-00 N/A N/A -03
FLANGE OS&Y X MONITORED BFV W-2892-00 W-5249-00 N/A N/A -04
FLANGE OS&Y X FLANGE POST INDICATOR W-2892-00 W-2873-00 E-3027-00 C-2778-00 -06
FLANGE OS&Y X GROOVE OS&Y W-2892-00 W-2898-00 N/A N/A -07
GROOVE OS&Y X GROOVE OS&Y W-2898-00 W-2898-00 N/A N/A -08
MONITORED BFV X MONITORED BFV W-5249-00 W-5249-00 N/A N/A -09
FLANGE OS&Y X GROOVE POST INDICATOR W-2892-00 W-2879-00 E-3027-00 C-2778-00 -010
GROOVE NRS X GROOVE NRS W-2879-00 W-2879-00 N/A N/A -011
FLANGE NRS X GROOVE NRS W-2873-00 W-2879-00 N/A N/A -012
FLANGE POST INDICATOR X MONITORED BFV W-2873-00 W-5249-00 E-3027-00 C-2778-00 -013
FLANGE POST INDICATOR X FLANGE POST INDICATOR W-2873-00 W-2873-00 E-3027-00 C-2778-00 -014
MONITORED BFV X FLANGE POST INDICATOR W-5249-00 W-2873-00 E-3027-00 C-2778-00 -016
FLANGE POST INDICATOR X GROOVE OS&Y W-2873-00 W-2898-00 E-3027-00 C-2778-00 -017
GROOVE OS&Y X GROOVE POST INDICATOR W-2898-00 W-2879-00 E-3027-00 C-2778-00 -018
MONITORED BFV X GROOVE POST INDICATOR W-5249-00 W-2879-00 E-3027-00 C-2778-00 -019
FLANGE POST INDICATOR X FLANGE OS&Y W-2873-00 W-2892-00 E-3027-00 C-2778-00 -020
GROOVE POST INDICATOR X GROOVE OS&Y W-2879-00 W-2898-00 E-3027-00 C-2778-00 -021
GROOVE POST INDICATOR X MONITORED BFV W-2879-00 W-5249-00 E-3027-00 C-2778-00 -022
MONITORED BFV X FLANGE OS&Y W-5249-00 W-2892-00 E-3027-00 C-2778-00 -023
SHUT-OFF VALVES
