Apollo RPLF4A User Manual

20
Customer Service (704) 841-6000
www.apolloflowcontrols.com
“Apl”
Flow Controls
INSTALLATION, OPERATION & MAINTENANCE
MANUAL
RP4A / RPDA4A (MAINLINE) / RPDA24A (MAINLINE) PARTS LIST
RPLF4A / RPDALF4A (MAINLINE) / RPDA2LF4A (MAINLINE) PARTS LIST
ITEM # DESCRIPTION QTY.
PART NUMBER
8” 10” 12”
1 Shut-o Valve 2 See Page 26 & 27
2 Nipple 2 K-3412-00
3 Test Cock, FxF 2 77CLF-104-10
4 Valve Body 2 Consult Factory
5 Screw 2 B-2348-00 B-1690-00
6 Relief Valve Sub-Assy 1 W-9676-05 W-2329-05
7 O-ring, RV Port 1 D-4963-00 D-2304-00
8 Plug, 1/2" NPT 1 K-4594-05 N/A N/A
9
Coupling 2 W-9791-00 W-5242-00 N/A
Bolt Pack 2 N/A N/A 40-00H-BP
10 Test Cock 1 77CLF-804-10 77CLF-104-10
11 Second Check Module 1 W-9673-05 W-9862-05
12 Cover Clamp 1 W-9243-00 W-9355-00
13 Cover 1 E-2898-05 Q-7064-19
14 Test Cock, Cover 1 77CLF-804-10 77CLF-104-10
15 Locknut, 1/2-13 (QTY) C-2638-00 (24) C-2638-00 (32)
16 RP First Check Module 1 W-9674-05 W-9863-05
17 Check O-ring 1 D-4935-00 D-4997-00
18 Seat/Spring Sub-Assy 1 W-9721-05 W-9723-05
19 Disc 1 D-4934-00 D-4960-00
20 Disc Retainer 1 F-3899-00 F-3903-00
21 Washer 2 E-2897-00
22 Handle 2 H-3828-00 H-3813-00
23 Adapter w/ Extension 1 K-4618-00 N/A
24 Elbow, Street 1 K-4600-00 N/A
25 Nipple 1 K-3982-00 N/A
26 Sensing Hose 1 W-9898-00 W-9898-00
27 Street Elbow 1 K-4600-00
28 RV Body 1 Q-6992-05 Q-7102-05
29 RV Seat O-ring 1 D-4883-00 D-3506-00
30 RV Seat 1 L- 8 0 47- 0 0 L- 8 1 69 - 0 0
31 Bushing O-ring 1 D-2565-00 D-4858-00
32 RV Module 1 W-9675-05 W-2330-05
33 Diaphragm 1 D-2564-00 D-2591-00
34 RV Cover 1 Q-6994-05 Q-7103-05
35 Screw (QTY) B-1796-00 (8) B-1703-00 (8)
36 Nipple 1 K-3460-00
37 Screw 1 B-1753-00 B-1796-00
38 Washer 1 E-2200-00 E-2210-00
39 RV Disc 1 D-2563-00 D-2595-00
40 RV Stem 1 G-3240-00 G-4858-00
41 RV Stem O-ring 1 D-2562-00 D-2594-00
42 Bushing 1 I-9269-15 I-9431-15
43 Spring 1 A-1742-00 A-1749-00
44 Diaphragm Plate (QTY) E-2201-00 (1) E-2209-05 (2)
45 Screw 1 N/A B-1800-00
Individual parts are only available for bulk sales. Please refer to the appropriate repair kits on page 21.
Note: All bronze components listed are lead-free*
*LEAD FREE: The wetted surfaces of this product shall contain no more than 0.25% lead by weighted average. Complies with CA
AB1953, VT Act 193, MD HB372, LA HB471, and Federal Public Law 111-380.
PARTS LIST - 8” - 12”
