Apollo RPLF4A User Manual

35
Customer Service (704) 841-6000
backflow.apollovalves.com
ES1600 REV A.
BFMMRP4ALBF
TYPE 1 BYPASS RP PARTS LIST
ITEM DESCRIPTION PART# QTY
1 Body Q-6891-05 1
2 Nameplate I-9169-00 1
3 Nameplate Tack I-2614-00 2
4 Test Cock 78LF-292-01 4
5 Cap F-3847-05 2
6 Cap O-Ring D-4881-00 2
7 Check Module O-Ring D-4880-00 2
8 RV Cover Bolts B-1793-00 4
9 RV Cover F-3891-05 1
10 RV Diaphragm D-2632-00 1
11 RV Seat O-Ring D-4892-00 1
12 RV Seat L-7 8 9 4 - 0 0 1
13 RV Bushing Face O-Ring D-4893-00 1
14 1st Check Module S-Assy (see table below) W-9207-05 1
15
2nd Check Module S-Assy (see table
below)
W-9075-05 1
16 RV Module S-Assy (see table below) W-9586-05 1
Individual parts are only available for bulk sales. Please refer to the appropriate repair kits below.
TYPE 1 BYPASS RP CHECK MODULE PARTS LIST
ITEM DESCRIPTION PART# QTY
17 Check Seat L-7 8 1 5 - 0 0 1
18 Screw B-3279-00 1
19 Disc Retaining Washer E-2372-00 1
20 Seat Disc D-4771-00 1
21 Poppet K-4491-00 1
22 Spring, First Check A-2514-00 1
23 Spring, Second Check A-2505-00 1
24 Spring Retainer L-7 8 1 4 - 0 0 1
Individual parts are only available for bulk sales. Please refer to the appropriate repair kits below.
TYPE 1 RELIEF VALVE MODULE SUBASSEMBLY PARTS LIST
ITEM DESCRIPTION PART# QTY
25 RV Diaphragm Plate Screw B-1749-00 1
26 RV Diaphragm Plate E-2222-00 1
27 RV Spring A-2542-00 1
28 RV Bushing I-9225-00 1
29 RV Stem O-Ring D-4891-00 1
30 RV Stem G-4791-00 1
31 RV Seat Disc D-4833-00 1
32 RV Seat Disc Washer NONE 1
33 RV Seat Disc Screw B-3254-00 1
Individual parts are only available for bulk sales. Please refer to the appropriate repair kits below.
Note: All bronze components listed are lead-free*
*LEAD FREE: The wetted surfaces of this product shall contain no more than 0.25% lead by weighted average. Complies with CA
AB1953, VT Act 193, MD HB372, LA HB471, and Federal Public Law 111-380.
PARTS LIST & REPAIR KITS – BYPASS RP (TYPE 1)
BYPASS RP REPAIR KITS
CHECK RUBBER REPAIR KIT
4A-003-01: Kit includes items 6, 7, and 20 (1 ea.)
RP FIRST CHECK REPAIR KIT
4A-003-03: Kit includes items 6, 7, and 14 (1 ea.)
RP SECOND CHECK REPAIR KIT
4A-003-02: Kit includes items 6, 7, and 15 (1 ea.)
RP RELIEF VALVE RUBBER KIT
4A-005-04: Kit includes items 10, 11, 13, 29, and 31 (1 ea.)
RP RELIEF VALVE COMPLETE KIT
4A-005-05: Kit Includes items 10, 11, 12, 13, and 16 (1 ea.)
RP COMPLETE RUBBER KIT
4A-005-09: Kit includes items 6, 7, and 20 (2 ea.), 10, 11, 13, 29, and 31 (1 ea.)
