103N / 105N / 106
EN
Figure 2. Battery Replacement.
Battery
Cover
Battery Box
1.5V
Battery
Screw
Screw
Figure 3. Fuse Replacement
Top Case
Fuse 1
15A (600V)
1A (600V)
Screw
Screw
Screw
Battery Cover
Bottom
Case
19
