Electrical Specifications
(1) Test Frequency :
Accuracy
100Hz
120Hz
1kHz
10kHz
100Hz
± 0.05%
± 0.05%
± 0.05%
± 0.05%
± 0.05%
Frequency
(2) Test Signal :
AC Signal Level : 600mVrms
AC Signal Accuracy : ± 10%
DC Bias Level : 1V
DC Bias Accuracy : ± 10%
Accuracy : ± (A x B) (% of reading)
A : Basic Accuracy as specified by
B : Test Cable Accuracy
B(%) = 1 + (L x F x T)
L(m) : Cable Length
F(MHz) : Test Frequency
T : Cable Type. If the cable is 4-Wire type, the ʺT" is 40, and the
other is 4,000.
Model
SMD Test Probe
4-Wire Test Probe
Alligator Clip Set
60cm
60cm
15cm
1MHz
1MHz
1kHz
4-Wire
4-Wire
2-Wire
Length Bandwidth Type
(3) Test Cable :
When measuring by basic accuracy that following
conditionsmust be met :
● Ambient temperature: 23°C ± 5°C < 80%RH.
● Test cable length: 0 m
● Open and short corrections have been performed.
● D ≤ 0.1 for C, L measurements; Q ≤ 0.1 for R measurements.
See the operation manual for additional conditions.
