BATTERY REPLACEMENT
The tester is powered by a single 9V battery. To change the battery, refer to Fig.2 and follow the instructions given
below.
1. Remove the test leads from the component being tested, switch the tester off (move on/off switch to "OFF") and
unplug the test leads from the input terminals.
2. Lay the tester front-face-down on a work surface and unscrew the three screws in the bottom half of the case.
3. Lever up the end of the bottom half of the case closest to the LCD display until it releases from the top half with
a slight click.
4. Take the battery out of the top half of the case and carefully unplug the connector from it.
5. Press the connector onto the new battery until it clicks home and insert the battery into the top half of the case.
Make sure that the connecting wire will not be caught between the two halves of the case.
6. Fit the bottom half of the case back onto the top half. As you do so make sure that the O-rings on the case
screws are correctly seated and that the two hooked lugs are engaged in the top half. Screw the three screws
back in.
