4
Specifications
2.1 General specification
Display : 31⁄2 digit 1999 count LCD display.
Polarity indication : Automatic, positive implied negative indicated.
Over range : "1" or "-1"
Low battery voltage indication : "=" shown if the voltage from the battery drops below the operating voltage.
Measuring Tate : 2 times per second, nominal.
Operating temperature : 0 to +50°C, 0 to 80% RH.
Storage temperature : –20 to +60°C, 0 to 80% RH. When battery removed from meter.
Temperature coefficient : 0.15 x specified accuracy/°C, <18°C or >28°C.
Power required : Standard 9V battery, NEDA 1604, JIS 006P, IEC 6F22.
Battery life : Approx. 200 hours on alkaline battery.
Dimensions (L x B x H) : 84 x 175 x 31 mm, without holster.
95 x 192 x 50 mm, with holster.
Weight (includ battery) : 340 gms without holster
550 gms with holster
Accessories : Protective Holster, Battery and Operators Manual
