APPA 97II - DC CURRENT SPECIFICATIONS; DC Current Ranges and Accuracy

10
(3) DC Current
Range Resolution Accuracy Voltage Burden
±(1.5% reading + 2 digits) 200mV max
±(1.5% reading + 2 digits) 2V max
±(2.0% reading + 2 digits) 2V max
30mA 10µA
300mA 0.1mA
10A 10mA
Overload Protection : 1A (500V) fast blow fuse 10KA breaking capacity @440Vac for mA input.
Size = 32mm x 6.3mm
10A (500V) fast blow fuse 10KA breaking capacity @440Vac for A input.
Size = 32mm x 6.3mm
