APPA 97II - AC CURRENT SPECIFICATIONS; AC Current Ranges and Accuracy

11
(4) AC Current
Range Resolution Accuracy Voltage Burden
±(2.0% reading + 5 digits)
200mV max
2V max
±(2.5% reading + 5 digits) 2V max
30mA 10µA
300mA 0.1mA
* 10A 10mA
* Frequency Response : 40Hz ~ 1KHz.
Overload Protection : 1A (500V) fast blow fuse 10KA breaking capacity @440Vac for mA input.
Size = 32mm x 6.3mm
10A (500V) fast blow fuse 10KA breaking capacity @440Vac for A input.
Size = 32mm x 6.3mm
* AC Conversion Type : Average Sensing rms indication.
