11
Crest Factor : +1.5% addition error for C.F. from 1.4 to 3 where C.F. = Peak
+3.0% addition error for C.F. from 3 to 4 RMS
(3) DC Current
Range Resolution Accuracy Voltage Burden
±(0.6%reading + 2digits) 200mV max
±(0.7%reading + 2digits) 2V max
±(1.0%reading + 3digits) 2V max
40mA 10µA
400mA 0.1mA
10A 10mA
Overload Protection : 1A (500V) fast blow fuse (10KA breaking capacity @ 440Vac) for mA input.
(size 32 × 6.3 mm)
10A (500V) fast blow fuse (10KA breaking capacity @ 440Vac) for A input.
(size 32 × 6.3 mm)
