12
(4) AC Current
Range Resolution Accuracy Voltage Burden
±(2.0%reading + 5digits)
200mV max
2V max
±(2.5%reading + 5digits) 2V max
40mA 10µA
400mA 0.1mA
10A 10mA
Frequency Response : 40Hz ~ 1KHz.
Overload Protection : 1A (500V) fast blow fuse (10KA breaking capacity @440Vac) for mA input.
(size 32×6.3mm)
10A (500V) fast blow fuse (10KA breaking capacity @440Vac) for A input.
(size 32×6.3mm)
AC Conversion Type : AC conversions are ac-coupled true rms responding, calibrated to the rms value sine
wave input.
Crest Factor : +1.5% addition error for C.F. from 1.4 to 3 C.F. = Peak
+3.0% addition error for C.F. from 3 to 4 RMS
