USA Dimensions & Power: International Dimensions & Power:
Tested to meet ANSI 12:12.01 (Cl.1, Div.2, Gr. D T4A) Tested to meet ANSI 12:12.01 (Cl.1, Div.2, Gr.D T4A)
G5Twin UL Certified Test Results
Per ARI 740-2016 - as of March 2016
* Uses high speed direct liquid mode; 8.16lb (3.7kg) with standard recovery.
** With external cooling accessory (see Page 16); R22 is 0.60lb (0.27kg) with standard recovery; R134a is 0.44 lbs (0.20 kgs) with standard
recovery.
20
Machine Specifications
G5TWIN OPERATION MANUAL
© 2022 APPION INC. - ALL RIGHTS RESERVED
REPAIR KIT ORDERING INFORMATION
PART NO. DESCRIPTION (CONTENTS)
KTGA00 2-Pack of 0-700 PSI Gauges
KTG520-R Compressor Repair Kit (valves, springs, seals, seal o-rings, slide rings)
KTG535 Front Ball Valve Seal Replacement Kit (input/output seals, o-rings)
MODEL # G5TWIN SPECIFICATIONS
LENGTH 349 mm
HEIGHT 262 mm
WIDTH 239 mm
WEIGHT 11 kgs
POWER 230 VAC, 50/60 Hz, 5 Amps
LENGTH 13.75 in
HEIGHT 10.3 in
WIDTH 9.4 in
WEIGHT 24 lbs
POWER 115 VAC, 60 Hz, 10 Amps
PUSH PULL
RATE
DIRECT LIQUID
RATE
VAPOR RATE FINAL
RECOVERY
VACUUM
REFRIGERANT
LOSS,
WEIGHT %
RESIDUAL
TRAPPED
REFRIGERANT
HIGH TEMP
VAPOR
RECOVERY
RATE 104F
(40C)
kg/min lb/min kg/min lb/min kg/min lb/min kPa inHg kg/min lb/min
R134a
2.91 6.41 2.56* 5.64* 0.14** 0.3** 28.54 8.42
<3 0 n/a n/a
R22
5.67 12.5 2.85 6.28 0.2 0.44 51.88 15.32
<3 0 0.28** 0.62**
R410a 4.38 9.65 2.2 4.85 0.14 0.30 56.96 16.82
<3 0 n/a n/a
R32 6.22 13.71 1.85 4.07 0.09 0.19 50.53 14.92 <3 0 n/a n/a
RELATED ACCESSORY ORDERING INFORMATION
PART NO. DESCRIPTION (CONTENTS)
MGAVCR MegaFlow™ Valve Core Removal Tool - 5/16in.
MGAVCT MegaFlow™ Valve Core Removal Tool - 1/4in.
MH380006AAY MegaFlow™ 3/8 in. Hose - 6 . (1/4FL to 1/4FL) Yellow
MH380004AAY MegaFlow™ 3/8 in. Recovery Output Hose - 4 . (1/4FL to 1/4FL) Yellow
A2L Users: Please contact Appion Inc. at www.appiontools.com to get your machine serviced.
Non-A2L Users: Repair kits and parts may be ordered from Appion Inc. at www.appiontools.com.
