Apple iMac (24-inch) - Screw Chart - Part 3 of 3

iMac (24-inch) Views 232
922-7814 T10, machine
Logic board to chassis (3)
922-7817 T6
Optical ex cable to optical
drive (2)
922-7970 T8
Video card to logic board (2)
922-7971 T10
Video card heatsink support
(1)
922-7972 spacer
Video card to logic board (2)
922-XXXX
Logic board, 9mm, (on right
and left side of memory slot)
Screw Chart: iMac (24-inch) page 3 of 3
