Mac Pro (Early 2008) Take Apart — Optical Drive Carrier and Optical Drives 22
Replacing the Optical Drive Carrier and Optical Drives
Important: Use the original Apple cables that came with the computer when you install or
replace the optical drives. If just one optical drive is installed, tuck the cables for the second drive
out of the way.
Attach the power and ribbon cables to the back of the drive(s). 1.
Important: Attach the connector on the end of the optical drive ribbon cable and the
connector in the middle of the optical drive power cable to the top drive. If there is a second
drive in the carrier, attach the remaining optical drive ribbon and power connectors to the
bottom drive.
Slide the optical drive carrier over the guides and into place in the optical drive bay. 2.
Important: Be very careful not to catch the cables under the carrier as you slide it into the
bay.
