Features
Power
• 5 VDC or 12 to 160 VDC, draws less than 500 mw
• Power cable can be removed/inserted with power on
• "Hot Card Swap" on rack mount configuration
Timings
• Carrier detect on delay: 2 to 30 msec.
• RTS/CTS delay: 0 to 254 msec. or constant CTS
Levels
• Transmit Gain: 0 to –31 dB, switch selectable, 1dB increments
• Receiver Gain: –35 or -45 dB, switch selectable
Isolation
• 1,500 VAC Telco
• 1,800 VAC Power Supply
LEDs
• LEDs for transmit (TD) and receive (RD) data, RTS, CTS, carrier detect (CD), and power
Connections
• Analog side via 4-wire RJ-11
• Digital side via DB-25 RS-232
Other
• 2-wire or 4-wire (2-wire with optional 156 msec. receiver squelch)
• Constant or switched carrier
• 900Hz soft carrier turn-off
Packaging
The modem dimension is based on a VME form-factor PC card (100 x 160mm) that can be mounted in an
optional metal box (Model 5006), inserted into a VME-style rack (Model 5008), or mounted in a customer
enclosure (Model 5006) with 4 4-40 screws. The metal box dimensions are 7.35 x 4.14 x 1.42” (187 x 105
x 36 mm) and include flanges with 4 mounting holes. For the rack mount version, power is provided
through the backplane connector. For the Model 5006, power connection is via a 3-position terminal block.
