Key:
1. Oil pipe screw
2. Front brake pipe
3. 10x14x1.6 Washer
4. M6x30 TE flanged screw
5. Valve
6. Pump-valve pipe
7. Front calliper-valve pipe
8. Rear calliper-valve pipe
9. Air bleed
10. Air bleed cap
Rear brake disc
Braking system SCARABEO 125 - 200
BRAK SYS - 160
