AIR EXCHANGE
Rain
sensor
Wind
detector
Actuator
Max 10
CV10
CONTROL DEVICE FOR AIR EXCHANGE SYSTEMS
Power supply: 230V - 50 Hz - 24V transformer. The CV 10 control unit can be
connected to a maximum of 10 linear or 5 Apri Color actuators.
The control switch, either the PUL 3 type or a standard type, must be connected
directly to the CV 10 control device. Several CV 10 control devices can be connected
in parallel using a single PUL 3 type centralised switch. Alternatively, several CV 10
control devices can be connected in parallel to an automatic emergency RAIN-WIND
system using a single PUL 3 type switch for each control unit for normal opening and
closing operations.
Dimensions: 15 x 20 x 8 cm.
Pul 3
MANUAL SWITCH
PUL 3 type press and release switch. Complete with a box for wall mounting.
