Tianjin APT Science and Technology Co., Ltd.
1001, Building 5 HuaDing, No.1 HuaKe 3 Road,
Binhai hi-tech Industrial Development Zone, Tianjin, China
2
TEL: 86 22 2634 5859
FAX: 86 22 8371 9955
Email: apt@aptdevelop.com
1． Product Name
² TFT LCD display
² Model : APT TFT 850C
2． Suppliers
² Tianjin APT Science and Technology Co., Ltd.
² Email : yzhao@aptdevelop.com apt@aptdevelop.com
3． Electrical Parameters
² 3.2inch IPS screen
² 24V/36V/48V battery supply
² Rated operating current : 40mA
² Max operating current : 100mA (36V battery, with USB equipment changed)
² USB changing port : 5V 500mA
² Off leakage current < 1uA
² Max output current to controller : 100mA
² Operating temperature : -20～70℃, Storage temperature : -30～80℃
4． Dimensions & Material
² Product shell is ABS, transparent window is made with high strength Acrylic.
² Dimensions : host/L92mm*W60mm*H14mm
