6 Accessories
6.1 Tractor cable set (Item no.: 00410-2-022)
Cable length: 8 m
Connection diagram: Red (6 mm² cable) = 12 Volt
Red (1.5 mm² cable) = Ignition plus
Black (6 mm² cable) = Ground
For the power supply to the control box, without a standard 3-pin standard socket
on the tractor, a retrofit kit is available as an accessory.
The cable is 8 m long.
It is screwed directly on the terminals of the battery on the battery side, and at the
other end, a 3-pin standard socket is installed.
Fig.: 5
