Aqua Computer LEAKSHIELD User Manual

LEAKSHIELD
or selection or speed adjustment. Additionally, many effects can be configured to
modify effect parameters depending on current sensor data.
In total, up to eight LED controllers (two for integrated lighting, six for external
components) can be configured.
14.2.
14.2.14.2.
14.2. Modify existing LED controllers
Modify existing LED controllersModify existing LED controllers
Modify existing LED controllers
Existing LED controllers can be selected by clicking the corresponding col-
or bars, the configuration of the selected controller can then be modified
in the lower area of the window.
By clicking the gear symbol, the effect to be displayed can be changed and the
controller name can be altered. Confirm you selection by clicking the check sym-
bol in the lower right corner.
14.3.
14.3.14.3.
14.3. Modify LED assignments
Modify LED assignmentsModify LED assignments
Modify LED assignments
Existing LED controllers can be moved by using “drag&drop”on the corre-
sponding color bars. The horizontal position of the color bar defines the
position of the effect on the connected LEDs. The vertical position deter-
mines the priority of the LED controllers, if multiple controllers are assigned to a
range of LEDs. Controllers positioned further up in the list have higher priority than
controllers further below.
The length of the bar (corresponding to the number of LEDs assigned) can be
changed by moving the right/left edge of the color bar.
14.4.
14.4.14.4.
14.4. Duplicate LED controllers
Duplicate LED controllersDuplicate LED controllers
Duplicate LED controllers
Select the LED controller(s) to be duplicated and click the duplicate sym-
bol to create new LED controllers using identical configurations. Alterna-
tively, use the right mouse button and select “Duplicate” from the context
menu.
In total, up to eight LED controllers (two for integrated lighting, six for external
components) can be configured.
14.5.
14.5.14.5.
14.5. Delete LED controllers
Delete LED controllersDelete LED controllers
Delete LED controllers
Select the LED controller(s) to be deleted and click the delete symbol to
delete the selected controllers. Alternatively, use the right mouse button
and select “Delete” from the context menu.
15.
15.15.
15. Alarm configuration
Alarm configurationAlarm configuration
Alarm configuration
Select “Alarms” from the device list below the “LEAKSHIELD” entry.
- 24 - Aqua Computer GmbH & Co. KG © 2021
Gelliehäuser Str. 1, 37130 Gleichen
c
o
m
p
u
t
e
r
a
q
u
a
