30
Series SC
Installation, Operation,and
Maintenance Manual
SET
CLOCK
SOFTENING
650
®
GAL
CAPACITY REMAINING
NEXT
REGEN
Parts Diagrams
1
2
3
4
6
8
11
13
10
9
5
7
Tank Assemblies
No.Part No. Description Qty.
1a 04210890 Tank Shroud for 44" Tank 1
1b 04210891 Tank Shroud for 47" Tank 1
1c 04210892 Tank Shroud for 54" Tank 1
2 see data sheet Resin Tank 1
3a 03510871 Turbulator Distributor (spec size) 1
3b 03510877 Standard Distributor (spec size) 1
403810800 High Capacity Resin spec size
5 spec size Brine Tank Cover 1
6a 03410758 Brine Tank w/ IM Cover 18x40 1
6b 03410755 Brine Tank w/ IM Cover 11x11x36 1
7 spec size Salt Shelf 1*
8 spec size Brine Well 1
903310663 Brine Well Cap 1
10 03310720 474 Safety Brine Valve 1
11 03310715 474 Float Assy 1
12 03310710 474 Air Check Assy 1
13 03310654 Overflow Ass
y
1
12
