At the end, the unit will power-off automatically.
6. Serial Port
The unit can receive a certain number of commands from the RS-232 serial interface.
The 9-pin DB-9 connector is located on the rear of the unit.
RS-232 parameters to be used: 9600,n,8,1
The commands are made up of 4 characters preceded by '*' and followed by '#'.
At least 100 mS must elapse between one command and the other (1 Sec in the case of the
power-on command).
For monitoring, the command received is immediately re-transmitted by the device (the
communication parameters remain the aforementioned 9600, n, 8, 1).
RS232 Commands:
*PWR1# : power-on
*PWR0# : power-off
*MOD1# : module 1 select
*MOD2# : module 2 select
*MOD3# : module 3 select
*MOD4# : module 4 select
